A5.2
Specifications
A5.2.1 Selective optical power meter
Optical Measure bands
Connector
Measurement Dinamic Range
Input
Accuracy
Isolation between bands
A5.2.2 Optical to RF converter
Dynamic range of conversion
Atenuación RF
RF band converted
Optical Cable and DTT links
Optical IF-Satellite Installations
RF output
52
1310 nm ± 50 nm.
1490 nm ± 10 nm.
1550 nm ± 15 nm.
FC/APC.
- 49,9 dBm to +10 dBm.
± 0,5 dB.
> 45 dB
From -5 dBm to +10 dBm
ON = 15 dB
OFF = 0 dB
From 65 MHz to 1000 MHz.
From 950 MHz to 5450 MHz. (For universal optical LNB)..
From 65 MHz to 2150 MHz.
