MEASUREMENT 3/3: MEASUREMENT + PARAMETERS
Selected installation, date and time.
Number of view/total views.
Selected band, battery level.
Demodulation parameters of the locked signal.
Measurement values for the type of locked signal.
Signal status (searching/locked/multiplex name).
Softkeys menus.
Joystick right/left
►
"Signals description" annex describes in detail the measurement parameters for
each type of signal.
April 2013
Figure 26.
It changes the selected channel/frequency.
:
3-33
