DVB-S2 SIGNAL PARAMETERS
Symbol rate (QPSK)
Symbol rate (8PSK)
Roll-off (α) factor
of Nyquist filter
Code Rate (QPSK)
Code Rate (8PSK)
Spectral inversion
Pilots
TOOLS
DATALOGGER function
Stored data
Timestamp
SAT IF TEST Function
Test frequencies
ATTENUATION TEST Function
band)
Test frequencies
VIDEO & AUDIO
Format
Aspect Ratio
SI/PSI data
HD Video Resolution
Audio
1
Using NetUpdate4 software application with a Windows PC platform.
2
Function to be used with RP-250 or RP-050 IF multiple pilot generator.
3
Function to be used with RP-250 or RP-080 multiple pilot generator.
April 2013
2 to 45 MSps.
2 to 45 MSps.
0.20, 0.25 and 0.35.
1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10.
3/5, 2/3, 3/4, 5/6, 8/9, 9/10.
ON, OFF (AUTO).
Presence indication.
1
(Automatic measurement acquisition and storage)
Signal type, modulation parameters, all measures available for the
detected signal type, and time stamp.
Date and time at each measured channel.
2
(IF distribution network response for satellite band)
3 selectable pilots.
3
(Signal distribution network response for terrestrial
3 selectable pilots.
MPEG-2 (MP@HL) (Main Profile High Level). MPEG-4 AVC H.264.
16/9 or 4/3.
Service list and main PIDs.
1080, 720 and 576, progressive or interlaced.
MPEG-1, MPEG-2, HE-AAC.
9-101
