9 SPECIFICATIONS

9.1 Specifications
CONFIGURATION FOR MEASURING LEVEL AND POWER
TUNING RANGE
Tuning modes
R esolution
RF INPUT
Impedance
M aximum signal
Maximum input voltage
DC to 100 Hz
5 MHz to 2150 MHz
DIGITAL SIGNALS MEASUREMENT
TERRESTRIAL TUNING RANGE
S ATELLITE TUNING RANGE
M ARGIN OF POWER MEASUREMENT
COFDM
QAM
QPSK/8PSK
April 2013
HD +
RANGER
Digital frequency synthesis. Continuous tuning from 5 to 1000 M
and from 950 to 2150 MHz (terrestrial and satellite respectively).
Channel or frequency (IF o
configurable on demand.
10 kHz.
75 Ω.
130 dBµV.
50 V rms (powered by the AL-103 power charger).
30 V rms (not powered by the AL-103 power charger).
140 dBµV (protected up to 30 seconds).
From 45 to 1000 MHz.
From 950 to 2150 MHz.
From 35 dBµV to 115 dBµV.
From 35 dBµV to 115 dBµV.
From 35 dBµV to 115 dBµV.
r downlink at satellite band). Channel set
Hz
