4.5.3

F3: Tools

Access by the
depending on the type of selected standard. Tools are:
Explore channel
►
set:
Constellation:
►
LTE Ingress Test:
►
Echoes:
►
Mer by carrier:
►
Merogram:
►
Datalogger:
►
Spectrogram:
►
For more information about these features, see the "Tools" chapter.
4.5.4

F4: Advanced

Access by the
display the spectrum.
The advanced menu consists of the following options:
Average:
►
4-44
key. It shows the Tools menu. This menu can change
It explores the selected channel set.
It displays the constellation of the locked signal.
It enables the detection of signal interferences coming
from mobile phones.
It detects the echoes that may appear due to the
simultaneous reception of the same signal from several
transmitters.
This function analyses continuously the measure of the
MER value for each one of the carriers forming the
selected channel and they are displayed in a graphic on
screen.
This function shows a graphical representation of the
MER level for each carrier of the locked signal, which is
superimposed over time.
It creates a file in which are stored measurements. This
file belongs to the selected current installation.
This function shows a graphical representation of the
spectrum superimposed over time of a channel or
frequency selected by the user.
function key. It allows selecting among several parameters to
The user can select the amount of signal values to be used
to set the average signal value to be displayed on screen.
The larger the average value, the more stable the displayed
signal appears.
