6.2.3

Menu options for the LTE Ingress Test tool

On the bottom of the screen there are four menus accessible via the function
keys.
6.3

Echoes

6.3.1

Description

The Echoes function shows the response in time of a digital terrestrial channel
and therefore it
reception of the same signal from several transmitters with different delays
and amplitudes.
Another cause that may cause echoes is reflection of the signal on
objects, as buildings or mountains. This may be the explanation that having a
good C/N and a good signal, the BER does not reach the minimum value.
With the Echoes function is possible to know the distance from where the
equipment is to the transmitter or the object that caused the echo
installer can minimise the effect that the echo may cause on the installation,
reorienting the antenna and reducing the effect of received echoes.
This function is only available for DVB-T, DVB-T2 and DVB-C2. Therefore,
previously have to configure the equipment for the reception of such signals.
April 2013
It displays channel/frequency and access the tuning
menu. It allows selecting the channel where apply
the LTE ingress test.
It displays the selected transmission standard menu
and accesses the signal parameters.
It displays the Tools menu.
It enables (ON) / disables (OFF) the LTE filter.
can detect echoes that can occur due to the simultaneous
large
. Thus, the
6-61
