Channel Set:
►
Tune by:
►
Central Frequency:
►
Place over the Frequency option and press the joystick.
The option is highlighted in yellow to indicate it is in edit mode.
Move the joystick left/right to move between the figures and up/down
to change the figure.
When finished press joystick to save the selected value or any function
key to exit without saving.
Reference level:
►
Place over the Reference Level option and press joystick.
The option is highlighted in yellow to indicate it is in edit mode.
Move the joystick left/right to move between the figures and up/down
to change the figure.
When finished press joystick to save the selected value or any function
key to exit without saving.
The Reference Level can be changed directly with the joystick up or
down.
Span:
►
Place over the span option and press the joystick.
The option is highlighted in yellow to indicate it is in edit mode.
Move the joystick left/right to move between the figures and up/down
to change the figure.
When finished press joystick to save the selected value or any function
key to exit without saving.
The span can be changed directly with the joystick in SP mode.
4-42
This option allows the user to select a channel set
from the ones available for the current installation.
It allows the user to select between tuning by channel
(selecting a channel or channel by channel with the
joystick)
frequency or step by step with the joystick).
It displays the value of the central frequency on the
screen. To edit:
It displays the reference level. To edit:
It shows the span, which is the frequency range displayed on
screen. To edit:
and tuning by frequency (selecting
April 2013
