5.4

IRG Descriptor

The analyser is compatible with IRG recommendations and it can extract the
Carrier ID information and display it conveniently showing all the details.
This information is useful to identify the interference, thanks to the carrier ID.
This identifier provides enough information to detect the interference source
(customer name, contact data, geo coordinates, etc.) and allows the operators to
communicate directly with the RFI source to resolve the incident.
IRG descriptor function is available only for signals containing the carrier
identifier. To access this feature:
Connect the RF input signal to the equipment.
Tune the channel that produces interferences.
Access to TV mode.
Press the Advanced menu
Select the TS Data option. If the signal has a carrier identifier, this
option is enabled. If the signal does not contain this identifier, this
option is disabled.
The IRG descriptor window is displayed with the data about the
provider (see figure below).
April 2013
.
Figure 39.
5-55
