ANALOGUE SIGNALS MEASUREMENT
LEVEL MEASUREMENT
Measurement range
Terrestrial TV & FM bands
Satellite TV band
Attenuation scale
Numerical indication
Graphical indication
Measurement bandwidth
Audible indicator
Accuracy
Terrestrial band
Satellite band
Out of range indication
RF MEASUREMENTS
Terrestrial bands
Analogue channels
Digital channels
Satellite band
Analogue channels
Digital channels
9-102
15 dBµV to 130 dBµV (3.16 µV to 3.16 V).
20 dBµV to 130 dBµV (31.6 µV to 3.16 V).
Auto-range.
Absolute value according to selected units.
Analogue bar on screen.
100 kHz.
Pitch sound. A tone with pitch proportional to signal strength.
±1.5 dB (25-120 dBµV, 45-1000 MHz) (22 °C ± 5 °C).
±1.5 dB (35-100 dBµV, 950-2050 MHz) (22 °C ± 5 °C).
<, >.
Level, Video-Audio ratio, Carrier-Noise ratio.
Channel power, Carrier-Noise ratio.
Level and Carrier-Noise ratio.
Channel power and Carrier-Noise ratio.
