Pressing up or down will change the reference level regardless the active mode.
The frequency or channel tuning mode will appear depending on the selected
tuning type. Access the TUNE BY
To show the MARKER mode, it must be active.
Access the ADVANCED menu
Pressing the joystick for 1 second, a box appears explaining the joystick modes
available. From here user can also select the active mode.
4.5

Menu options for the SPECTRUM ANALYSER

At the bottom of the screen four menus are accessible via the function keys.
Next each one of these menus is described.
4-40
to activate the MARKER.
Figure 32.
It displays the channel where is pointing the cursor
and gives access to the tuning menu.
It displays the selected transmission standard and
gives access to the signal parameters menu.
It displays the Tools menu.
It displays the Advanced menu.
menu to select the type of tuning.
