ANNEX 5
A5.1
GENERAL
A5.1.1 Description
This annex contains operating instructions for the next option:
OP-001-PS: Selective Optical Power Meter +
The evolution of the telecommunications market, more and more demanding in
quality standards, speed, services and so on and also economical and
competitiveness
installations, and increasingly, fibre-optics is being imposed on traditional ADSL
twisted-pair copper lines.
For this reason and in anticipation of an increase of fibre-optics installations, this
option has been developed. It is applicable to the
allows adapting it in order to work with fibre-optics networks.
This optical module expansion includes two separate functions: The selective
optical power meter and the selective optical to RF converter.
The selective meter option allows measurements on optical fibre networks, which
are necessary to certify an installation according to the parameters set by local
policies.
The selective optical to RF converter option directly receives optical signals and
modulates them in RF. With this option, user can measure terrestrial or cable (up
to 1 GHz) networks or optical LNB for satellite antennas (up to 5.45 GHz), so
that the installer does not need any additional equipment to measure this type of
installations.
With this module, the equipment becomes a true "all in one" for the
telecommunications installer, as all benefits available to RF (terrestrial, satellite,
cable) can be used for optical fibre signals.
This expansion module is available for
equipments or to upgrade equipments owned).
April 2013

OPTICAL OPTION OP-001-PS

Optical to RF Selective Converter.
factors has changed the trend
HD
HD
RANGER/
in telecommunications
analysers and
+
RANGER/
unit (both for new
+
51
