Step 1. Capturing reference measurements.
►
Connect the SC pigtail end connector to the PROLITE-105 output
connector.
Connect the FC end of the pigtail to the optical input of the
HD + (see figure below).
RANGER/
HD +
RANGER/
Turn on the PROLITE-105 and the .
In the HD + , from the SPECTRUM or MEASUREMENT
RANGER/
screen, press key to access the Tools menu.
Select the FIBRE OPTIC TEST option and press the joystick.
In the PROLITE-105, press once the SEQ key to select the
SIMULTANEOUS mode. This mode simultaneously sends three
wavelengths signals.
HD +
RANGER/
In the , press the key Set Reference. All current
values are captured, which will be used as reference values.
Now, user can proceed to Stage 2 in order to measure the attenuation
at each user's access point.
Figure A5.4.
