Promax HD RANGER+ Manual page 106

SPECTRUM ANALYSER MODE
Measurement range
Satellite band
Terrestrial bands
Resolution filter
Measurement bandwidth
Terrestrial
Satellite
Span
Terrestrial
Satellite
Markers
Reference level
Measurements
Terrestrial band
Analogue channels
Digital channels
Satellite band
Analogue channels
Digital channels
Spectrum range
ANALOGUE TV MONITOR DISPLAY
Monitor
Aspect ratio
Dot format
Brightness
TV STANDARD
Colour system
Standard supported
Sensibility
9-96
10 dBµV to 130 dBµV (3.16 µV to 3.16 V).
10 dBµV to 130 dBµV (3.16 µV to 3.16 V).
100 kHz.
100 kHz.
100 kHz.
Full span (full band) - 500 - 200 - 100 - 50 - 20 - 10 MHz selectable.
Full span (full band) - 500 - 200 - 100 - 50 - 20 - 10 MHz selectable.
1 with frequency and level indication.
65 dBµV to 135 dBµV, adjustable in steps of 5 dB.
Level, C/N, V/A.
Channel power, C/N, MER and BER (according to modulation type).
Level, C/N.
Channel power, C/N, MER and BER (according to modulation type).
Span, dynamic range and reference level are variable by means of
arrow cursors.
7 inches TFT. Transmissive colour dot matrix type.
16:9.
800 (R,G,B)(W) × 480(H) dots.
700 cd/m2.
PAL, SECAM and NTSC.
M, N, B, G, I, D, K and L.
40 dBµV for a correct synchronism.
