Multiswitch (2 Satellites)
A3.5.2
This type of multiswitch is used usually to switch the Astra 19º and Hotbird 13º
satellites.
As in the previous case, if for a certain satellite it is desired to change of band or
polarisation, it is not sufficient with changing the corresponding parameter, but in
addition it is necessary to send the command SAT A/B corresponding to cause
the switching (even if one does not change of satellite).
Band
Low
Low
High
High
Low
Low
High
High
April 2013
Figure A3. 7.
Polarization
Horizontal
Vertical
Horizontal
Vertical
Horizontal
Vertical
Horizontal
Vertical
Command
SAT A
SAT A
SAT A
SAT A
SAT B
SAT B
SAT B
SAT B
Output
Satellite-1
Satellite-1
Satellite-1
Satellite-1
Satellite-2
Satellite-2
Satellite-2
Satellite-2
