MEASUREMENT 2/3: MEASUREMENT + TV + SPECTRUM
Figure 25.
Selected installation, date and time.
Image of the locked signal.
Number of view/total views.
Selected band, battery level.
Spectrum of the locked signal.
Measurement values for the type of locked signal.
Signal status (searching/locked/multiplex name).
Softkeys menus.
Joystick right/left
It changes the selected channel/frequency.
:
►
3-32
April 2013
