6.7.2

Operation

To create a new datalogger:
First select the installation on the Installations menu and load it
pressing the "Load" key . An installation contains the channel sets
and DiSEqC commands selected by the user and it stores dataloggers
and screenshots made while it is selected (more information in chapter
7 Installations Management).
Check the installation is selected. The name of the installation should
appear on the upper left corner of the screen.
Enter the MEASUREMENT mode or the SPECTRUM mode.
Press the : Tools key.
Press on the "Datalogger" option.
It displays a menu with the "New ..." option and a list of all
dataloggers at the selected installation.
Select "New ..." to create a new datalogger or select the file name of
an existing datalogger if the user want to save data on a specific
datalogger already existing.
If "New ..." is selected, a installation wizard shows how to create a
new datalogger. Follow its instructions ( : Next to move to the next
screen, : Previous to move to the previous screen or : Cancel to
cancel).
During the creation of a new datalogger using the wizard, the user can
assign a name and select the channel sets. The channel sets are the
ones available for the current installation. At least one channel set has
to be selected, either terrestrial or satellite. The wizard also gives an
option to select if during datalogger user wants to capture the list of
services (it slows down the process but gives more information) and
also if user wants a pause between channel sets (the process stops
until the user resume it). At the end user has the option to open the
new datalogger (by default, these last three options are enabled).
Once a new datalogger is created or selected an already existing one,
it shows the datalogger viewer screen and measurements of test
points can start.
If it is a new datalogger, in first place before starting the datalogger,
user must create a new test point (see next section).
