After the exploration the following screen appears:
The window is divided into three areas:
Spectrum and Measurement
It shows the cursor scrolling through each of the channels of the channel
set. On the bottom of the screen the channel and frequency appears next
to the Power/Level and the C/N ratio.
Progress Bar
It shows the signal type detected and the scan progress in real time. At
the end a box shows a message informing the exploration process has
finished.
Channel set
At the end of the process it shows the channels that have been detected
during the channel set exploration. In parentheses shows the number of
detected channels to total channels of the channel set.
6-78
Figure 49.
