75 Status_ AC Return Temp
76 Status_ Error/Alarm
Error 77 Status_ Error Code
78 Status_ Error Text code
79 Status_Lock Remote Control
Locking
80 Statu_Lock Control Objects
81 Status_ Power Mode
82 Status_ Econo Mode
Special
Modes
83 Status_ Additional Heat
84 Status_ Additional Cool
Counter 85 Status_ Operation Hour Counter
Scene 86 Status_ Current Scene
87 Legacy_ Mode
Legacy 88 Legacy_ Fan Speed
89 Legacy_ Vane Up-Down
90
Status_ Inx - Switching
92
Status_ Inx – Dimming - On/Off
94
Binary
Status_ Inx – Shut/Blind - Step
Inputs
96
91
Status_ Inx – Value
93
Status_ Inx – Value
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
2 byte DPT_Value_Temp 9.001
1 bit DTP_Alarm 1.005
2 byte Enumerated
14 byte DPT_String_8859_1 16.001
1 bit DPT_Bool 1.002
1 bit DPT_Bool 1.002
1 bit DPT_Switch 1.001
1 bit DPT_Switch 1.001
1 bit DPT_Switch 1.001
1 bit DPT_Switch 1.001
DPT_Value_2_Ucou
2 byte 7.001
nt
1 byte DPT_SceneNumber 17.001
1 byte Enumerated
1 byte Enumerated
1 byte Enumerated
1 bit DPT_Switch
1 bit DPT_Switch
1 bit DPT_ShutterBlinds
1 byte DPT_Value_1_Ucount
2 byte DPT_Value_2_Ucount
R T ºC value in EIS5 format
R T 0 - No Alarm; 1 - Alarm
R T 0 - No Error; Any other see user's manual
R T 2 char Daikin Error; Empty - none
W T 0 - Unlocked; 1 - Locked
W T 0 - Unlocked; 1 - Locked
R T 0 - Off; 1-On
R T 0 - Off; 1-On
R T 0 - Off; 1-On
R T 0 - Off; 1-On
R T Number of operating hours
R T 0 to 4 - Scene 1 to 5; 63 - No Scene
R T 0 - Auto; 1 - Heat; 2 - Dry; 3 - Fan; 4 - Cool
R T 0 - Speed 1; 1 - Speed 2; 2 - Speed 3
R T 0 to 4 - Pos 1 to Pos 5; 5 - Swing
1.001 R T
1.001 R T
1.023 R T
5.010 R T
7.001 R T
