IntesisBox KNX - Daikin A.C. (SKY & VRV line)

4.5 Vane Up-Down Configuration dialog

All the parameters in this section are related with the Vane Up-Down properties and
communication objects.

4.5.1 Indoor unit has Up-Down Vanes

This parameter lets you choose if the unit has Up-Down Vanes available or not.
If set to "no" all the parameters and communication objects for the Up-Down Vanes will
o
not be shown.
If set to "yes" all the parameters and communication objects (if enabled in the parameters
o
dialog) for the Up-Down Vanes will be shown.
Important: Read the documentation of your indoor unit to check if Up-Down Vanes are
available.

4.5.2 Enable "Control_ Vane U-D Swing"

This parameter shows/hides the Control_ Vane Up-Down Swing and Status_ Vane Up-Down
Swing communication object.
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
Figure 4.16 Vane Up-Down Configuration dialog
Figure 4.17 Parameter detail
User's manual r1.0 eng
URL http://www.intesis.com
Email info@intesis.com
tel +34 938047134
28 / 66
