IntesisBox
KNX - Daikin A.C. (SKY & VRV line)
5. Specifications
Dimensions:
Weight:
KNX current consumption:
P1-P2 Bus current consumption:
Operating Temperature:
Stock Temperature:
Isolation voltage:
Binary inputs
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox
is a registered trademark of Intesis Software SL
70 X 70 X 28 mm
70 g
5 mA
45 mA
-25 . . . 85ºC
-40 . . . 85ºC
2500 V
4 x Potential-free binary inputs.
Signal cable length: 5m uschielded, may be extended
up to 20m with twisted.
Compliant with the following standards:
IEC61000-4-2: level 4 - 15kV (air discharge) - 8kV
(contact discharge)
MIL STD 883E-Method 3015-7: class3B
User's manual r1.0 eng
URL
http://www.intesis.com
Email
info@intesis.com
tel
+34 938047134
55 / 66
