IntesisBox KNX - Daikin A.C. (SKY & VRV line)
This parameter lets choose a debounce time (in milliseconds) that will be applied to the
contact.

4.9.4 Disabling function

This parameter shows/hides the Control_ Disable Input x communication object which will let
disable/enable the input x.
If set to "no" any object will be shown.
o
When "DPT 1.003: 0-Disable; 1-Enable" is selected, the input can be disabled using
o
the value "0" and enabled using the value "1".
When "DPT 1.002: 1-True (Disable); 0-False (Enable)" is selected, the input can be
o
disabled using the value "1" and enabled using the value "0".
4.9.5 Function
This parameter lets choose the function that will have the binary input. There are 7 different
functions available: Switching, Dimming, Shutter/Blind, Value, Execute Scene (internal),
Occupancy (internal) and Window Contact (internal).
When "Switching" is selected the communication object and new parameters for the
o
Input "x" will appear as shown below.
 Send telegram after bus recovery
This parameter lets select if the Binary Input "x" will send a telegram, or not, after a
bus recovery, and the type of telegram sent (if enabled).
 When "No action" is selected, no telegram will be sent after a bus recovery.
 When "Current status" is selected, the binary input will send a telegram with
its current status after a bus recovery. Also a new parameter will appear (see
below).
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
Figure 4.39 Parameter detail
