Focus: see focus on page 27
Vertical Picture offset: vertical compensation for the center shift of image (see note).
Lens Zoom-Focus Calibration: Perform zoom and focus motors calibration
There is the possibility to save the settings for the positions of zoom, focus, vertical shift corre-
sponding to a video format for each type of signal, for each input of the projector. (see "Memo -
ries" on page 27)
Note: In the case of off-axis projection, zooming in and out, you get a changing of the center of
the image corresponding to the amount of the off-axis. This changing amount must be compen -
sate with the vertical and/or horizontal shift.
With some setting positions, the range of lens shift may be restricted, even though the unit is in -
stalled within the specified parameters.
Test Patterns
Enters internal test patterns, that are needed for installation or calibration purposes. Press ▴ or
▾ on the remote control or on the projector keypad to cycle through the test patterns. To exit
test patterns press Esc on the remote control or on the projector keypad.
Note: OSD menus are not available while test patterns are displayed.
Initial Settings
Resets most projector settings to their factory presets. The settings in the following list are not
reset:
Serial Number and Model name
•
Lamp Hours
•
User Memories (including Memories Names)
•
Source List (including Source Names)
•
Orientation
•
Zoom and Focus
•
Y/C Delay
•
Position
•
Note: Before performing this operation, a confirmation message appears. Press ▸ to Confirm
and continue with the reset or press ◂ to Cancel.

Menu

This menu section provides access to OSD adjustments.
Language
Selects the desired OSD language. The AR can display the menus in English, Italian, French, Ger-
man, Spanish, Swedish, Portuguese, Russian and Simplified Chinese.
Source List
Allows customization of the Input list. To change the status of an input:
1. highlight the input
2. use the ◂ and ▸ keys to Enable or Disable the input.
Disabled inputs are not shown in the input selection menu and cannot be selected via keys 1-5
of the remote control.
Important:
tus of an input modifies the numbers assigned to the inputs that follow (which is undesirable if
you
You can change the label of each input (for example assigning the name of the device it is con-
nected to). To rename an input:
1. highlight the input
2. press ● on the remote control to enter Text Entry menu
3. use the ◂ and ▸ keys to underline the character you would like to change
4. enter the desired symbol using keys 1-9 on the remote control
SIM2 BV International s.r.l
Active inputs are numbered according to their position in the list. Changing the sta-
are using a custom control system).
