Introduction

The AUTOCAL® allows to use new features into the projector main menu.
After the successful connection of the probe to the projector, the color sensor submenu will be
available under the Color menu.

Key Features and Benefits

Multi-functional measuring device technologically advanced and ergonomic.
•
COLOR SENSOR software for measurement and calibration of the luminance and colorimetry
•
according to the lighting conditions of the enviroment.
Intelligent Ambient Light Control - measurement, compensation and ongoing monitoring of
•
ambient lighting conditions.
Control of the white point, luminance, contrast ratio and gamma correction.
•

System Components

1 pcs Color Probe
•
1 pcs Probe Bracket (with screws)
•
1 pcs User Guide (this document)
•
If any of the items listed above are missing or damaged, contact your SIM2 Authorized Dealer. Keep
the original packaging in case anything has to be shipped.

Installation

This section provides instructions for the installation of the AUTOCAL®.
Important:

Location

When installing the AUTOCAL®, take the following considerations into account.
There are two possible types of installations:
1. SCREEN
2. AMBIENT
For the first case the probe allows to measure the native colors (in order to preserve the lamp life),
the compensation of the white point and the presence of ambient lighting (non-continuous
measurement). The installation of the probe should be done in such a way that the lens is directed
toward to the center of the screen where the image is projected.
In the second case the probe allows to perform a compensation in the ongoing time of the ambient
light background. The installation of the probe should be done in such a way that the lens is directed
towards a point in the room where to measure the environmental conditions of projection.
In both cases, the probe lens cap has to be lifted up.
SIM2 BV International s.r.l
Installation procedure should be performed by a qualified AV system specialist.
AR User Guide 37
