The AR is designed for use with large screen sizes – up to 5 m (16.5 ft.) wide. A choice of three
high quality glass lenses (T1, T2 and T3) is available, giving the projector a total throw ratio of
1.37-3.90:1.
To aid calibration SIM2's Live Color Calibration software enables complete control over:
primary, secondary and white point color coordinates
•
gamma tables
•
allowing calibration experts to accurately calibrate the final image via a user-friendly application
for Windows-based computers.

Key Features and Benefits

high picture quality: SIM2 renown image processing and the latest 0.95 in. 1080p Dark-
•
Chip4 DMD from Texas Instruments
precision optics: SIM2 ALPHAPATH light engine
•
high brightness: 3-chip DLP projector
•
artifact-free fast-action images: SIM2 PureMotion processing
•
high resolution: actual full HD 3D images, without blur and ghosting
•
larger color gamut: dual gamut (REC 709/DCI) via a motorized Sliding Filter System
•
comfortable 3D viewing: high brightness ghost-free sharp images
•
immersive 3D effect: large screen sizes thanks to high brightness images
•
3D wide viewing angle: stereo separation independent from viewing angles
•
screen flexibility: no constraints in the choice of the screen material
•
compatibility: no need of dedicated sources and preprocessing for 3D viewing
•
longer lamp life: affordable and reliable UHP lamps
•

System Components

Your AR DLP projector ships with the following items:
1 x backlit remote control unit (with four AAA/LR03 batteries)
•
1 x SIM2 3D sync RF emitter (ADE025-RF-S1)
•
4 x pairs of SIM2 X105-RF-S1 active shutter glasses
•
1 x AC power cords 2 m (6.6 ft.) long
•
3 x jacks for 12 V output connectors
•
1 x 4.0-millimeter Hex wrench (for lens shift adjustment)
•
1 x User guide (this document)
•
1 x Professional calibration probe
•
If any items are missing or damaged, contact your SIM2 Authorized Dealer as soon as possible.
Keep the original packaging in case anything has to be shipped.

Optional Accessories

Projector ceiling bracket (LUMISBRKT)
•
PANAMORPH Anamorphic lens systems (static or motorized)
•
ISCO Anamorphic lens systems (static or motorized)
•
VISUSRF-BOX (8 SIM2 Visus 3D RF glasses)
•
VISUSRF-SYSTEM (7 SIM2 Visus 3D RF glasses and 1 RF emitter for SIM2 Visus 3D RF glas-
•
ses)
VISUSRF-SYSTEM-ACC (4 SIM2 Visus 3D RF glasses and 1 RF emitter for SIM2 Visus 3D RF
•
glasses)
