every attached device at the same it is connected, reducing drastically the time required for
HDMI source switching. For this reason you may note a slight delay before the image appears on
the screen, but it is perfectly normal.
Graphics RGB Input for Personal Computer and other sources that outputs RGB or YPrPb
•
signals. These sources must be able to provide separate H/V sync or composite H+V
sync.
RGB/YPrPb Input for DVD Players, Set Top Boxes and other sources that output one of
•
the following signals:
◦ Component (YPrPb)
◦ RGB with composite sync on green (RGsB)
◦ RGB with HV composite sync
RGB connectors also provides RGB input for SCART RGBS sources. See "Video" below and "RGBS
Sync" on page 25.
Video This is the the input for composite video sources (such as VCR or camcorders).
•
This connector is also the composite sync input for SCART RGBS sources. See
"RGB/YPrPb" above and "RGBS Sync" on page 25.
Control
You can connect the AR projector to a Personal Computer or a control system through one of the
following methods:
RS-232 port, using a standard 9-pin straight serial cable
•
RS-232 port, using a USB to serial converter cable. In this case, installation of a device
•
driver provided by the cable manufacturer may be required
USB port, using a USB Type A cable connector. In this case, installation of a device driver
•
provided by SIM2 may be required – ask your SIM2 Authorized Dealer
Note: RS-232 communications are limited to 15 m (50 ft.), whereas USB are limited to 5 m (16
ft.).
Triggers
Some Home Theater devices can be controlled through a 12 V signal. The projector can output
three 12 V (100 mA max) signals:
TRIG1 for motorized screens control
•
TRIG2 and TRIG3 are for motorized screen masks and anamorphic lens motors control.
•
See "Screen" and "Anamorphic Lens" on page
configure them from OSD
Note: Three jack adapters are shipped with the projector.
3D RF Emitter
The RF emitter sends the RF pulses that sync the 3D glasses. Proceed as follows to install the
emitter:
1. Place the emitter near the projector on a secure surface or use an appropriate mount
kit. For maximum range emitter should not be placed on the ground/floor but should be
placed at least 10 cm above ground (like on a shelf).
2. Connect the emitter connector to the corresponding 3D Sync Out output connector in
the projector.
3. Once the emitter is connected to the projector, please make sure that the projector is in
3D mode. Check the X sign on the emitter; the red light should be on, indicating that the
emitter is functioning.
3D Glasses
Proximity Association with 3D RF emitter
The following procedure has to be done every time the glasses are introduced to new 3D RF
emitter. During the proximity association, 3D glasses shall be located within 1 m from 3D RF
emitter.
Switch on the glasses (1 short press on the button). LED will change from off to bright, indicating
SIM2 BV International s.r.l
23 for instructions on how to do
