5. cycle through steps 3 and 4 until you have finished entering your custom label
6. press ● on the remote control to save the label you have entered, or Esc to discard your
changes
F1-F2 Keys
You can have direct access to some functions through the F1 and F2 keys on the remote control.
The default assignments are: F1 = Zoom, F2 = Focus.
To assign a different function to one of these keys:
1. highlight the function using ▴ or ▾
2. press F1 or F2 to set the key assigned to that function.
Available functions are:
Zoom Activates the optical zoom control, where the ◂ and ▸ keys zoom out and in re-
•
spectively. By pressing
splayed. This is the default function for key F1.
Focus Once selected, ◂ and ▸ allow the image to be focused. By pressing
•
mote control a specific internal test pattern is displayed. This is the default function for
key F2.
Blank Turns off the video signal on-screen. Press Esc to restore video to the screen.
•
Gamma correction Activates Gamma Correction quick menu. Use ▴ or ▾ to cycle throu-
•
gh available Gamma tables.
Freeze Turns on or off picture still mode.
•
Source Information
When enabled (Yes), the projector displays information about the current input signal every
time a new signal is detected. If disabled (No) no information is displayed.
Help Menu
When enabled, the Help bar (providing tips for menu navigation) is displayed at the bottom of
the main menu.
OSD Background
Selects the background of the OSD (Clear or Solid).
OSD Position
Changes
To select one of the nine preset positions:
press 1-9 on the remote control
•
To create a custom position:
1. select the preset that is closest to the desired position
2. use ◂, ▸, ▴ or ▾ for a finer adjustment
Note: Avoid locations too close to corners or edges to prevent cropping of larger menus.
OSD Display Timeout
Sets duration OSD is visible after the last event. Adjust in 10 second increments from 10 to 200
seconds.

Presets

You can store and recall at a later time up to six different sets of values (preset) per input type,
so that you have customized setups for each viewing condition. Each memory saves the main
image settings that are available for a given input type. Refer to Table 4.5 for details.
Table 4.5
Settings
Brightness
SIM2 BV International s.r.l
●
the location for
Video
on the remote control a specific internal test pattern is di-
the display
RGB/YPrPb
Graphics RGB
● ●
of the Main
HDMI 1/2 HDMI 1/2
2D 3D
● ●
AR User Guide
●
on the re-
Menu OSD.
27
