Projection Distance

Screen
Diagonal Width
Size (in.) (m)
100 2.21
120 2.66
150 3.32
180 3.98
200 4.43
220 4.87
250 5.53
280 6.20
300 6.64
Screen
Diagonal Width
Size (in.) (in.)
SIM2 BV International s.r.l
Normal (Full Height), Anamorphic, Letterbox, Panoramic, Pixel
to pixel, Subtitle, User (3)
Includes REC 709 and DCI: Fully adjustable with presets (HDTV,
EBU, SMPTE-C, DCI)
 Requirement: 100-240 V AC ±10% @ 48-62 Hz
 Operating Consumption: 440 W
 Standby Consumption: < 1 W
 Depth: 455 mm (17.9 in.)
 Width: 460 mm (18.1 in.)
 Height: 210 mm (8.3 in.)
 Weight: 13 kg (28.6 lb.) approx.
 Operating: 10° C to 35° C
 Storage: -15° C to 55° C
 Low Voltage Directive: EN 60950-1/UL60950
 EMC Directives: EN 55022, EN 55022 A1 A2, EN61000-3-2,
EN61000-3-3
1.78:1 (16:9) Screen
T1 (1.37-1.66:1)
Height Min Max
(m) (m) (m)
1.25 3.03 3.73
1.49 3.65 4.48
1.87 4.58 5.62
2.24 5.52 6.76
2.49 6.14 7.52
2.74 6.75 8.28
3.11 7.68 9.41
3.49 8.60 10.56
3.74 9.22 11.32
T1 (1.37-1.66:1)
Height Min Max
(in.) (ft.) (ft.)
Projection Distance
T2 (1.75-2.48:1) T3 (2.54-3.90:1)
Min Max Min
(m) (m)
3.92 5.22 5.76
4.72 6.38 6.91
5.93 8.24 8.63
7.13 9.96 10.36
7.94 11.07 11.51
8.74 12.18 12.66
9.96 13.84 14.39
11.15 15.50 16.12
11.94 16.60 17.27
Projection Distance
T2 (1.75-2.48:1) T3 (2.54-3.90:1)
Min Max Min
(ft.) (ft.) (ft.)
Vertical
Offset
(m)
Max
(m) (m)
8.63 0.62
10.36 0.75
12.95 0.93
15.54 1.12
17.27 1.25
18.99 1.37
21.58 1.56
24.17 1.74
25.90 1.87
Vertical
Offset
Max (in.)
(ft.)
