Table 4.2
3D Format
Frame Packing
Side by Side
Top and Bottom
Notes:
1. except Panoramic

Input Menu

The desired input can be selected by pressing the corresponding number key on the remote con-
trol or through the Input menu.
To enter the Input menu press:
•
Key 0 on the remote control or Source on the projector keypad.
To select an input press the corresponding number on the remote control, or:
•
To turn off the Input menu press:
•
Esc on the remote control or on the keypad
Each time an Input is changed an information window appears on the screen and remains there
until a valid signal is detected (this feature can be disabled in the Setup section of the main
menu, see "Source Information" on page 27).
If no signal is detected on the selected input, an appropriate message is displayed.

Main Menu

The main menu gives access to all projector adjustments. It is divided in four main sections (Pic-
ture, Image, Setup and Menu) with various item and submenus in each of them.
To enter the main menu and select the desired section press:
•
MENU + or MENU - on the remote control or on the keypad
To enter a submenu (when available) press:
•
●
on the remote control or on the keypad
To return to the previous menu when in a submenu press:
•
MENU + on the remote control or
To select menu items press:
•
MENU + or MENU - on the remote control or on the keypad
To turn off the main menu press:
•
Esc on the remote control or on the keypad
To change settings or select an item on a list press:
•
◂, ▸, ▴ or ▾ on the remote control or on the keypad
Note: Depending on the selected input source and signal characteristics, some adjustments may
not be available.
Picture and Image menu sections provide access to most commonly-used projector adjustmen-
ts. Note that:
you can enter these sections only when an image is displayed
•
the controls in these sections only operate on the active input
•
when you select another input or change mode (2D/3D), all the settings in these sec-
•
tions are automatically saved
SIM2 BV International s.r.l
Signal
1920 x 1080p @ 23.98/24 Hz
Others
All
All
1. ▴ or ▾ on the remote control or on the keypad to highlight the input
●
2. on the remote control or on the projector keypad to confirm
Aspect
●
-
● 1
-
●
on the keypad
Keystone
●
-
-
-
AR User Guide 20
