Programming Parameters

The following table provides the option-specific parameters that are
provided with each control option. These parameters are in addition
to those already discussed in the Basic Setup, Advanced Setup,
Metering, and Calibration groups. Diagrams supporting the options
described below are shown later in this chapter.
Option
Soft Stop SMC Option
This parameter identifies the type of
control present and is not user
programmable.
Soft Stop Time
Allows the user to set the time
period for the soft stopping function.
Pump Control SMC Option
This parameter identifies the type of
control present and is not user
programmable.
Pump Stop Time
Allows the user to set the time
period for the pump stopping
function.
Starting Mode
Allows the user to program the SMC
Dialog Plus controller for the type of
starting that best fits the application.
Preset Slow SMC Option
Speed This parameter identifies the type of
control present and is not user
programmable.
Slow Speed Select
Allows the user to program the slow
speed that best fits the application.
Slow Speed Direction
This parameter programs the slow
speed motor rotational direction.
Slow Accel Current
Allows the user to program the
required current to accelerate the
motor to slow speed operation.
Slow Running Current
Allows the user to program the
required current to operate the
motor at the slow speed setting.
Options
Parameter
Soft Stop
0–60 seconds
Pump Control
0–120 seconds
Pump Start, Soft Start,
Current Limit Start
Preset Slow
Low: 7% – forward,
10% – reverse
High: 15% – forward,
20% – reverse
Forward, Reverse
0–450% of full load
current
0–450% of full load
current
7-3
