2-4
Installation

Mounting

D
Unit
mm
24A
Controller
in.
6-1/16
mm
35A
Controller
in.
8-7/16
mm
54A
Controller
in.
9-39/64
All dimensions are approximate and are not intended for manufacturing purposes. Refer to the nearest Allen-Bradley sales office for complete dimension drawings.
C
A
B
C
Width
Height
Depth
154
180
185
7-3/32
7-19/64
214
240
195
9-39/64
7-11/16
244
290
225
11-22/64
8-7/8
The controller is convection cooled. Additionally, units rated for 97A
and above are fan cooled. It is important to locate the controller in a
position that allows air to flow vertically through the power module.
The controller must be mounted with heatsink fins in a vertical
plane and have a minimum of six inches (15 cm) free space above
and below the controller.

Dimensions

Figure 2.1 Dimensions: 24, 35, and 54 Amp Controllers
Ø .28 in.
(7.14 mm)
4 Mtg. Holes
Ø .22 in.
(5.56 mm)
4 Mtg. Holes
D
E
50
140
1-31/32
5-33/64
60
200
2-23/64
7-7/8
90
230
3-35/64
9-1/64
E
A
F
G
H
160
140
10
6-5/16
5-33/64
13/32
200
180
20
7-7/8
7-3/32
51/64
240
200
25
9-29/64
7-7/8
63/64
G
F
B
Ground Screw
(10-32)
Approx.
J
Ship. Wt.
20
4.5 kg
51/64
10 lbs.
30
6.8 kg
1-3/16
15 lbs.
45
11.3 kg
1-25/32
25 lbs.
