180–360 Amp
Refer to Figure 10.3 for control module reference.
1. Remove controller access door and serial port cable.
2. Remove controller cover.
3. Remove all control wires and loosen six control module mounting
screws.
4. Unplug control module from the interface board by pulling for-
ward.
