Example Settings

Parameter
Phase Reversal
This parameter allows the user to enable phase reversal
protection.
Starts Per Hour
Allows the user to limit the number of starts during a one
hour period.
Restart Attempts ①
Determines the number of attempts the controller will
make to automatically restart the motor after a fault.
①
Restart Delay
Provides a delay period prior to a restart attempt.
ETM Reset
Allows the user to reset the accumulated value of the
elapsed time meter.
②
Parameter Management
The newly programmed parameter values can be saved
to memory, or the factory defaults parameter values can
be recalled.
①
The Auto Restart feature is not available.
②
The new programmed parameter values will not be stored to the EEPROM without the user's
direction in parameter management: Store In EE

Undervoltage

①
With Line Voltage programmed for 480V and the Undervoltage level
programmed for 80%, the trip value is 384V.

Overvoltage

①
With Line Voltage programmed for 240V and the Overvoltage level
programmed for 115%, the trip value is 276V.

Jam

②
With Motor FLC programmed for 150 Amps and the Jam level
programmed for 400%, the trip value is 600 Amps.

Underload

②
With Motor FLC programmed for 90 Amps and the Underload level
programmed for 60%, the trip value is 54 Amps.
①
The average value of the three phase-to-phase voltages is utilized.
②
The largest value of the three phase currents is utilized.
Programming
Option
Off, On
0–99 (0 is the Off setting)
0 to 5
0 to 60 seconds
Off, On
Ready, Default Init., Recll
Frm EE, Store In EE
4-13
