7-2 Options
Option
Preset Slow Speed
Smart Motor Braking
Accu-Stop
Slow Speed with
Braking
ATTENTION: The Bulletin 1201 human interface
module's stop push button is not intended to be used as
!
an emergency stop. Refer to applicable standards for
emergency stop requirements.
Action
The green start button, when pressed,
will commence motor acceleration to
full speed.
The red stop button, when pressed, will
provide a coast stop.
The jog button, when pressed, will
JOG
initiate slow speed motor operation
from a "stopped" status.
The green start button, when pressed,
will commence motor acceleration to
full speed.
The red stop button, when pressed, will
provide a coast stop.
The jog button, when pressed, will
JOG
initiate a brake stop.
The green start button, when pressed,
will commence motor acceleration to
full speed.
The red stop button, when pressed, will
provide a coast stop.
With a "stopped" status, the jog button,
when pressed, will initiate slow speed
motor operation. From an "at speed"
condition, the jog button, when
JOG
pressed, will initiate braking to slow
speed operation. The controller will
maintain slow speed operation as long
as the jog button is pressed.
The green start button, when pressed,
will commence motor acceleration to
full speed.
The red stop button, when pressed, will
provide a coast stop.
With a "stopped" status, the jog button,
when pressed, will initiate slow speed
JOG
motor operation. From an "at speed"
condition, the jog button, when
pressed, will initiate a brake stop.
Operation
