Receiving

Unpacking

Inspecting

Storing

Installation
It is the responsibility of the user to thoroughly inspect the equipment
before accepting the shipment from the freight company. Check the
item(s) received against the purchase order. If any items are
damaged, it is the responsibility of the user not to accept delivery until
the freight agent has noted the damage on the freight bill. Should any
concealed damage be found during unpacking, it is again the
responsibility of the user to notify the freight agent. The shipping
container must be left intact and the freight agent should be requested
to make a visual inspection of the equipment.
Remove all packing material, wedges, or braces from within and
around the controller. Remove all packing material from the heat
sink.
After unpacking, check the item(s') nameplate catalog number
against the purchase order.
The controller should remain in its shipping container prior to
installation. If the equipment is not to be used for a period of time, it
must be stored according to the following instructions in order to
maintain warranty coverage.
• Store in a clean, dry location.
• Store within an ambient temperature range of –20°C to +75°C
(–4°F to +167°F).
• Store within a relative humidity range of 0% to 95%,
noncondensing.
• Do not store equipment where it could be exposed to a corrosive
atmosphere.
• Do not store equipment in a construction area.
