Product Overview
Slow Speed with Braking Option
The Slow Speed with Braking option provides a jog speed for process
set-up and braking-to-stop at the end of the cycle.
Figure 1.17 Slow Speed with Braking Option
100%
Motor
Speed
7% or 15%
Slow
Speed
ATTENTION: Accu-Stop and Slow Speed with
Braking are not intended to be used as an emergency
!
stop. Refer to applicable standards for emergency stop
requirements.
Run
Start
Time (seconds)
Coast-to-rest
Braking
Stop
