Figure 2.2 Dimensions: 97 And 135 Amp Controllers - Rockwell Automation SMC Dialog Plus User Manual

B
Unit
mm
97A
Controller
in.
mm
135A
Controller
in.
All dimensions are approximate and are not intended for manufacturing purposes. Refer to the nearest Allen-Bradley sales office for complete dimension drawings.

Figure 2.2 Dimensions: 97 and 135 Amp Controllers

A
Power Terminal
H
E M10 Bolt
6 Places
A B
Width Height
248 336
9-49/64 13-15/64
248 336
9-49/64 13-15/64
G
F
Fan
Terminals
.281 in.
(Ø 7.14 mm)
4 Mtg. Holes
C
D E
Depth
256.2 128 220
10-3/32 5-3/64 8-21/32
256.2 128 220
10-3/32 5-3/64 8-21/32
Installation
C
D
F G H
250 40.4 14
9-27/32 1-39/64 9/16
250 40.4 14
9-27/32 1-39/64 9/16
2-5
Ground
Screw (M6)
Approx.
Ship. Wt.
10.4 kg
23 lbs.
11.8 kg
26 lbs.
