Overview

Viewing Metering Data

Metering
While the SMC Dialog Plus controller operates your motor, it also
monitors several different parameters, providing a full function
metering package.
①
To access the metering information, follow the procedure below.
Description
—
1. Press any button to
access the Choose Mode
menu.
2. Scroll with the Up/Down
keys until the Display
option is shown.
3. Press the Enter key to
select the Display option.
4. Scroll with the Up/Down
keys until the Metering
option is displayed.
5. Press the Enter key to
access the Metering
group.
①
Refer to page 1-10 for details on the metering functions.
Chapter
Action Display
AT SPEED
—
###.# AMPS
CHOOSE MODE
_ _ _ _ _
CHOOSE MODE
or
DISPLAY
CHOOSE GROUP
_ _ _ _ _
CHOOSE GROUP
or
METERING
6
