3-14 Wiring
Standard Controller
Wiring Diagrams (cont.)
Figure 3.18 Typical Wiring Diagram for Bypass with Isolation Applications
Bulletin 825 Converter Module ➀
3-Phase
Input Power
Branch
Protection ➀
➀
➀
➁
11 12 13
SMC Dialog Plus
Control Terminals
IC
➀
To
Bulletin 825
Converter
Module
21 22 23
Fanning Strip
①
Customer supplied.
②
Refer to the controller nameplate to verify the rating of the control power input voltage.
Isolation
Fast-acting
Contactor
SCR Fuses
(IC) ➀
(optional) ➀
➀
BC
Stop ➀
Start ➀
14 15 16 17
Auxiliary contacts
set for Up-to-speed
24 25 26 27
Auxiliary contact
set for Normal and N.O.
➀
T1/2
L1/1
T2/4
L2/3
T3/6
L3/5
SMC Dialog Plus
Controller
Bypass Contactor (BC) ➀
➀
18 19 20
28 29 30
➀
M
