Configuration
For the initial configuration you can connect the PC to the OpenCom 510 via the
Ethernet port. The TCP/IP network protocol is used to set up a connection via one
of these ports. You can then open the Web console of the OpenCom 510 and call
up the Configurator from there.
8.1

Brief Guide to Initial Configuration

Setting up a first connection is quite simple with a standard Windows PC:
1. Connect the PC's network card with one of the OpenCom 510.'s LAN ports Use
a cross-wired Ethernet cable to do this.
2. Windows 2000/XP: log on as a user with "Administrator" rights.
3. You will find the IP settings in Windows 2000/XP under Start: Settings:
Network connections: Local Area Connection. Open the dialogue box Local
Area Connection Properties, and then the dialogue box Internet Protocol
TC/IP Properties (see figure: Setting the IP address in Windows XP on page 89).
4. Note down the existing settings so that you can restore them after completing
the initial configuration.
5. Change the IP Address to 192.168.99.253. Change the subnet mask to
255.255.255.0, confirm with OK and Close.
6. Start a Web browser and in the address field enter "http://192.168.99.254/".
The Web console's log-on page will be displayed. Enter the user name "Administ-
rator" without a password for the initial configuration. To support your next confi-
guration steps, you should activate the Assistant mode on the entry page of the
Configurator. Please also pay attention to the online help.
88
Note: In order to use all the new system software functions,
we recommend that you download the latest software from
our Web site at http://www.aastra-detewe.de.
Note: To avoid problems with existing network installations,
the OpenCom 510's DHCP server is designed for static
address assignment in its factory settings. The
OpenCom 510's IP address is always168.99.254 in its factory
settings.
