Configuration Examples

9.4.3 RAS Access

In a LAN with an IP-enabled server you can also enable external computers to dial
in via the OpenCom 510. To do this, you should coordinate with the network admi-
nistrator the IP address space which can be assigned to an external computer
dialling in, and enter it in the Configurator, NET Configuration: RAS: ISDN menu,
under Address Range.
ISP OpenCom
(DNS) (RAS, Internet)
S S Net
0 0
Ext. PC 1
PC
S Net
0
RAS access by the OpenCom 510 in a LAN with an IP server
The user account administered by the OpenCom 510, with which dialling in is per-
mitted, only allows the establishment of direct and anonymous TCP/IP connec-
tions such as HTTP, FTP or SMTP connections. If you additionally want to allow file
or printer access in the network, you must set up a suitable user account on the
addressed server for network log-in. If you use the same log-in name for the
OpenCom 510 user account and the same password for the network log-in, you
have to enter this combination only once when dialling in.
106
Server
(DHCP,
int. DNS)
Net
PC 2
Hub Net
Note: In a larger Windows network with several segments,
the lists of computer names visible in the network environ-
ment can no longer be established by broadcasts. In this case
you use a special WINS server whose address the
OpenCom 510 does not make known to the workstation
when dialling in with ISDN. For this reason, you enter the
address of a WINS server manually in the network settings of
the workstation.
OpenCom 510 in a LAN with an IP-enabled Server
