Technical Data
OpenCom 510: system configuration limits (single 19" frame)
Interface card maximal
(module) insertable
MS+A1-8 11
MT+A1-4 12
MG+ETH1-1 4
System configuration limits in general
CompactFlash 1
carte
200
Maximum num-
ber of interfaces
88 x a/b
48
4
–
Note: The online help provides an overview of the limits
that should be observed when configuring the
OpenCom 510.
Note
– with a single 19" frame (a
total of 12 slots) one slot is
required for the outside
line
– with a cascaded system
(two 19" frames) 12 inter-
face cards of this type can
be inserted in the 19"
frame of the slave system
for analogue trunk lines
– Ethernet port
(10/100 Mbits/s)
– with a cascaded system
(two 19" frames) 12 inter-
face cards of this type can
be inserted in the 19"
frame of the master system
–
