Modules
7.2

Overview of Available Modules

The following table provides an overview of modules available for the
OpenCom 510:
Name Description
MPS+1-AC Power supply with AC/DC transformer
MC+1-3 Central control module with three interfaces
MT+S2M1-1 Trunk module with one S
digital networks or for cascading two PBXs
MX+S01-8 Trunk or subscriber module with eight S
either external (trunk) or internal (subscriber) connec-
tions
MS+UPN1-8 Subscriber module with eight U
ting digital terminals (ISDN terminals, system telepho-
nes); does not support DECT base stations
MS+UPN2-8 Subscriber module with eight U
ting digital terminals (ISDN terminals, system telepho-
nes) and DECT base stations
MS+A1-8 Subscriber module with eight a/b interfaces for connec-
ting analogue terminals
MT+A1-4 Trunk module with four a/b interfaces for connecting to
analogue trunk lines
MG+ETH1-1 Media Gateway module for VoIP
The name of the module and the interface type are printed on the front of the
modules. The following illustration shows the printing on the MX+S01-8 interface
card.
Overview of Available Modules
interface for connecting to
2M
interfaces for
0
interfaces for connec-
pn
interfaces for connec-
pn
Page
65
68
72
76
79
81
83
85
118
63
