Accessories and Adapters
Electrical Data of Ports
Port
Microphone,
microphone of second handset,
headset microphone
Ear cap,
loudspeaker of second handset,
headset, headset loudspeaker
Active speaker
Recording device audio input
Recording device start/stop
(relay contact 1)
Door display
(relay contact 2)
6.4

Approved Devices / Approved Accessories

Please note:
The following devices are recommended:
Type
Headset:
Headset adapter cable:
Second handset
Handset
56
Only the following, recommended accessories may be con-
nected to the audio adapter. The cable to the door display
must not be run outdoors.
Approved Devices / Approved Accessories
Connection Values
Electret microphone
Typical sensitivity: 10 mV/Pa
Power feed: I < 300 µA at 1.5 V
Typical impedance: 150 ± 30 ohms
Typical sensitivity: 94 dB/1 mW
(0 dB = 20 µPa)
Max. output voltage: 1 V
at input impedance > 10 kohms
Typical input sensitivity: 0.24 mV
(microphone level)
Max. switching voltage:
50 VDC/29 V AC
Max. switching current: 1 ADC/0.7 A AC
Max. switching voltage: 50 VDC/29 V A C
Max. switching current: 1 ADC/0.7 A AC
Manufacturer, Product Designation
GN-Netcom, Profile binaural
(1869-00-03)
GN-Netcom, Profile 3-in-1 (1866-00-04)
GN Netcom, QD cable (quick coupling),
smooth, Mod 4 (8800-00-01)
Siemens, L30351-F600-A366
DeTeWe, OpenPhone 60
rms
