Interfaces and Connectible Terminals

5. Interfaces and Connectible
Terminals
5.1

Overview

The OpenCom 510 interfaces have been implemented as RJ45 sockets on the front
of the interface cards and the central control module. No special proprietary
cables are required. Patch panels can be connected by means of standard patch
cables.
For technical information on the interfaces, refer to Modules starting on page 61.
Interface Card
S MX+S01-8
0
S MT+S2M1-1 1 S
2M
U MS+UPN1-8 8 U
pn
U MS+UPN2-8 8 U
pn
a/b MS+A1-8
LAN MC+1-3
COM / V.24 MC+1-3
The following terminals and systems can be connected to the OpenCom 510's
interfaces:
Properties
8 S interfaces for either external or in-
0
ternal connections
interface for connecting to digital
2M
networks (primary multiplex connec-
tions) or for cascading two PBXs
interfaces, U
pn
DECT-capable
interfaces, U
pn
DECT-capable
8 a/b interfaces
1 Ethernet port (10/100 Mbits/s)
(on central control module)
2 V.24 ports
(on central control module)
interfaces are not
pn
interfaces are
pn
Overview
Page
76
72
79
79
83
68
68
39
