Voip System Telephones; Device Properties - Aastra OpenCom 510 User Manual

Voice over IP (VoIP)
You can configure SIP connections in the Configurator on the pages
PBX Configuration: SIP: Accounts and PBX Configuration: SIP: Provider. Enter
the technical attributes of a specific SIP provider, such as the IP addresses for the
registrar and the STUN server under Provider. Under Accounts enter the infor-
mation for an existing SIP account, such as the user name, password, assigned call
number and the maximum number of simultaneous calls possible.
10.4

VoIP System Telephones

The following telephones and software packages are available for VoIP system
telephony:
■
OpenPhone 63 IP: This is a VoIP capable edition of the OpenPhone 63 system
telephone.
■
OpenPhone 65 IP: This is a VoIP capable edition of the OpenPhone 65 system
telephone. This system telephone can be extended with up to three keypad
modules.
■
OpenPhone IPC: This VoIP software offers the functionality of a system tele-
phone using Windows 2000/XP executable software (see OpenPhone IPC
starting on page 127). Furthermore, this software offers local answering-
machine functionality and integrability with CTI applications.

10.4.1 Device Properties

The VoIP-enabled versions of the system telephones OpenPhone 63 IP and
OpenPhone 65 IP offer the same features as the corresponding system tele-
phones. Using VoIP system telephones is therefore not much different from using
standard system telephones. The following differences exist:
■
Two RJ45 connector ports are available for ethernet connection. The ports are
connected to one another via the telephone's internal switch. The switch sup-
ports 10 Mbit/s or 100 Mbit/s full-duplex with priority given to VoIP data trans-
mission.
LAN Port: Allows the telephone to connected to the LAN. Use a non cross-over
RJ45 patch cable to connect to a Hub or Switch.
122
VoIP System Telephones
