Installation

4.4.4 Installing Interface Cards

Interface cards can be installed or exchanged with the system powered up ("hot-
plugging"). Proceed as follows:
1. If you want to exchange an interface card, the slot for this card needs to be
deactivated first.
Open the PBX Configuration: Ports: Slots page in the Configurator. In the
table row listing the card to be exchanged, click on Stop. The system then
deactivates the slot. Any connections (telephone calls, data transfers) estab-
lished through this card will be terminated.
2. Remove the screws with which the interface card is secured in the 1-12 frame
and pull the card out.
3. Unpack the interface card and check whether it is the desired type. The type
designation is printed on the front of the card.
MX+S01-8
Detail: Printing on the front of an "MX+S01-8" type interface card
CAUTIONT!
4. Carefully push the interface card into the corresponding slot. The printing on
the front of the module should be at the top (see illustration in previous
instruction).
Static charge can damage electronic devices. Observe the re-
gulations regarding electrostatically sensitive components.
Installing Modules
31
