Installation
A Mounting bracket screw bolts for front mounting (approx. 132 mm) to the
uprights of the 19" rack
B Mounting bracket screw bolts for mid-mounting (approx. 400 mm) to the
uprights of the 19" rack
C Left and right screw points for earthing wrist strap or circuit common con-
nection between
1-12 frame and 19" rack
4.4

Installing Modules

A 0
C (1-6)
OpenCom 510: 1-12 frame slots
26
Note: If the OpenCom 510 is to be used as a wall-mounted
instead of a floor-standing system, it must be installed in a
standard-type wall-mounted enclosure using 19" mounting
technology.
B
D (7-12)
Installing Modules
