N :
OTE
This output does not provide information that the reserve is already reached.
It only gives information that there is enough capacity within the gen-set
group to reach the reserve.
Binary output: SystReserve OK
Related MINT
applications
Description The output is closed while the
selected reserve for start.
Binary output: EnginesSwapped
Related MINT
applications
Description The output is activated by the master controller for 100 ms pulse when the
priority of two gen-sets was swapped by the Running Hours Equalization
function (setpoint #RunHrsMaxDiff).

16.4.5 SPtM specific

Binary output: MCB Close/Open
Related SPtM
applications
Description This output is to be used for a contactor control in case a contactor is used
in the MCB position. See the chapter
outputs available for generator/mains power switches.
Binary output: MCB ON Coil
Related SPtM
applications
Description This output is to be used for control of the ON coil of the mains circuit
breaker. See the chapter
available for generator/mains power switches.
Binary output: MCB OFF Coil
Related SPtM
applications
Description This output is to be used for control of the OFF coil of the mains circuit
breaker. See the chapter
available for generator/mains power switches.
NT
InteliCompact , SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
Actual Reserve is greater than the currently
Circuit breakers
Circuit breakers for details about all outputs
Circuit breakers for details about all outputs
for details about all
273
