16.1.10 Group: Volt/PF Ctrl

Setpoint: AVRi Bias
Group Volt/PF Ctrl
Range [units] 0 ... 100.0 [%]
Related All
applications
Description This setpoint adjusts the initial PWM level for the AVR output, which is
present on the output, if no voltage or power factor regulation loop is active.
See the chapter
for various AVR types.
N :
OTE
The voltage level on the AVR remote voltage input depends also on AVRi
output wiring and potentiometer position.
Setpoint: Voltage Gain
Group Volt/PF Ctrl
0 ... 200.0 [%]
Range [units]
Related All
applications
Description Gain of the voltage control PI loop.
Setpoint: Voltage Int
Group Volt/PF Ctrl
Range [units] 0 ... 100 [%]
Related All
applications
Description Relative integration factor of the voltage control loop.
Setpoint: PF Gain
Group Volt/PF Ctrl
Range [units] 0 ... 200.0 [%]
Related All
applications
Description Gain of power factor control PI loop.
NT
InteliCompact , SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
AVR interface for details about the recommended settings
