Binary input: GCB Button
Related All
applications
Description This input is to be used as an external GCB button for control of the gen-set
in manual mode. It works the same way as the GCB button on the panel.
Binary input: ForwSyncDisabl
Related All
applications
Description If the input is active, the controller will not continue to synchronize after
Stab Time
fails), the gen-set will take the island load.
Binary input: NeutralCB fdb
Related All
applications
Description Use this input to detect whether the Neutral circuit breaker is open or closed.
See also setpoint
Binary input: PerFuelConsRes
Related All
applications
Description If the input is active, the controller will not continue to synchronize after
Stab Time
gen-set will take the island load.

16.3.2 MINT specific

Binary input: Sys Start/Stop
Related MINT
applications
Description This input activates the
not active, the gen-set is stopped in AUT mode and does not take part within
the power management of the group.
N :
OTE
In most cases this input is wired parallel into all controllers within the group
to activate and deactivate the whole group. If you want to deactivate one
particular gen-set, switch it out from AUT mode.
N :
OTE
If the power management is disabled by the
gen-set is started and stopped only according to this input.
NT
InteliCompact , SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
elapsed even in AUT mode. If an island condition occurs (mains
#Neutral cont and binary output
even in AUT mode. If an island condition occurs (mains fails), the
power management
Neutral CB C/O.
in the controller. If this input is
Pwr Management setpoint, the
